自動坐封井口堵塞器的研制及其評價試驗
打開文本圖片集
PingEnshun，Wang Yuzhong，Ren Baoliang，etal.Development and evaluation testof automatic-seting wellheadplug[J].ChinaPetroleumMachinery，2025，53（7）：136-140.
Development and Evaluation Test of Automatic-Setting Wellhead Plug
Ping Enshun1Wang Yuzhong'Ren Baoliang1 Zhao Lei’Li Di2Huang Feng1 Shao Junlong' （1.BHDC Dounhole Technology ServiceCompany;2.No.2Oil ProductionPlant，PetroChina Dagang Oilfield Company
Abstract： The wellhead device is prone to washout in the process of slug sand fracturing or blowing while production，which makes it impossible toaddress the risk of wellcontrol intime，thus imposing aserious potential safety hazard.An innovative automatic-seting wellhead plugand supporting hydraulic fishing tool were developed. In this paper，the main structures，working principles，main technical performance parameters and features of the deviceand tol were introduced，and thelaboratory performance evaluation test was performedon the physical prototypeof the automatic-seting wellhead plug.The test results show that under the15 MPawellore pressure，the stop pinof the automatic-setting wellhead plug is pulled toalowthe plug tofall into the wellbore freely， so as to realize automatic release and delayautomatic setting，and meet the requirement of sealing at 5O MPa.The hydraulic fishing toolcan beused to pressurize1O MPa torealize automatic unsealing and pressure relieffor equilibrium before the wellhead plug issafelylifted.The developed plug and tool are ready for field testing，and they have been proved effectiveforaddressing the problem of wellhead washout ina short time.Thus，the plug and tool are prospective for popularization and application.
Keywords： wellhead washout；automatic-seting；wellhead plug; hydraulic fishing tool; performance evaluation test
0 引言
隨著國內頁巖油氣大規模的勘探開發，橋塞射孔聯作體積壓裂技術得到廣泛應用。（剩余7445字）
