東勝氣田氣體射流泵排采工藝的設計及應用

打開文本圖片集

Zhou Ruili，Luo Yi，Qiao Qianyu，et al.Design andapplicationof fluid pump drainage gas recovery technology in Dongsheng gas field[J].China PetroleumMachinery，2025，53（7）：122-128.

Design and Application of Fluid Pump Drainage Gas Recovery Technology in Dongsheng Gas Field

Zhou Ruili Luo YiQiao QianyuWu Weiran Yang FeishanZhao Rundong Xue Zhaoyang （SinopecNorthChinaPetroleumCompany;SinopecKeyLaboratoryforExplorationandDevelopmentofDepCoalbedMethane

Abstract：To effectively addressthe bottleneck problems of high injection pressure and high energy consumptionof hydraulic jetpump technology，it is urgentto improve andoptimize the drainage gas recovery technologyof high water-production gas wells.First，based on the design principle of Venturi efect，the fluid pump technology using gas as jet medium was adopted to eficiently activate the production capacityof mediumand low-pressure high water production gas wellsand improve the technologyadaptability.Second，Well Q1 was selected toconductapplication evaluation offluid pump technology.The study results show that the fluid pump technology only needs 5- 7 MPa pressure to realize normal cleanup，the production time rate is up to 98.4 4% ，the liquid withdrawal capacity is18.42 times higher than thatof single well rotative gas lift technology，and thedailyliquidflowrate is 13.1 times higherthan thatof theelectric valve intermitentopening technology.Inaddition，itdoes notneed the assistance of foam-aided drainage gas recovery technology. Compared with the jet pump technology，the pump pressure is only 20.6%-32 3% of the jet pump，and the daily average power consumption is only 34. 6% - 75. 3% of the jet pump，fully verifying the effectivenessoflow pressure andlow energy consumption work of the fluid pump，and successfullysolving the problem of high injection pressure and high energyconsumption of hydraulic jetpump.The study results areof great significance for realizing continuous liquid-carrying gas production of gas wells and efficiently activating the production capacity of high water-production gas wells.

Keywords： Dongsheng gas field； fluid pump; drainage gas recovery; device design；application evaluation high water-production gas well

0 引言

鄂爾多斯盆地東勝氣田是國內已開發的水氣比最高的致密高含水氣藏，水氣比大于 10m3/104m3 的高產水區塊儲量規模近千億 。（剩余9837字）
